IXFZ520N075T2 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
IXFZ520N075T2
|
|
حجم فایل
|
201.625
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
7
|
مشخصات فنی
-
Manufacturer:
IXYS
-
Series:
GigaMOS™, TrenchT2™
-
Packaging:
Tube
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
75V
-
Current - Continuous Drain (Id) @ 25°C:
465A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
1.3mOhm @ 100A, 10V
-
Vgs(th) (Max) @ Id:
4V @ 8mA
-
Gate Charge (Qg) (Max) @ Vgs:
545nC @ 10V
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
41000pF @ 25V
-
FET Feature:
-
-
Power Dissipation (Max):
600W (Tc)
-
Operating Temperature:
-55°C ~ 175°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
DE475
-
Package / Case:
DE475
-
detail:
N-Channel 75V 465A (Tc) 600W (Tc) Surface Mount DE475
