VVZB 170 Series دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
VVZB 170 Series
|
|
حجم فایل
|
194.931
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
3
|
مشخصات فنی
-
Manufacturer:
IXYS
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Active
-
Structure:
Bridge, 3-Phase - SCRs/Diodes - IGBT with Diode
-
Number of SCRs, Diodes:
2 SCRs, 2 Diodes
-
Voltage - Off State:
1.6kV
-
Current - On State (It (AV)) (Max):
170A
-
Voltage - Gate Trigger (Vgt) (Max):
1.5V
-
Current - Gate Trigger (Igt) (Max):
95mA
-
Current - Non Rep. Surge 50, 60Hz (Itsm):
-
-
Current - Hold (Ih) (Max):
200mA
-
Operating Temperature:
-40°C ~ 150°C (TJ)
-
Mounting Type:
Chassis Mount
-
Package / Case:
E2
-
Base Part Number:
VVZB
-
detail:
SCR Module 1.6kV Bridge, 3-Phase - SCRs/Diodes - IGBT with Diode Chassis Mount E2
