MCNA120UI2200TED دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MCNA120UI2200TED
|
|
حجم فایل
|
475.549
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
7
|
مشخصات فنی
-
Manufacturer:
IXYS
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Active
-
Structure:
Bridge, 3-Phase - SCRs/Diodes - IGBT with Diode
-
Number of SCRs, Diodes:
3 SCRs, 3 Diodes
-
Voltage - Off State:
2.2kV
-
Voltage - Gate Trigger (Vgt) (Max):
1.4V
-
Current - Gate Trigger (Igt) (Max):
70mA
-
Current - Non Rep. Surge 50, 60Hz (Itsm):
500A, 540A
-
Current - Hold (Ih) (Max):
100mA
-
Operating Temperature:
-40°C ~ 150°C (TJ)
-
Mounting Type:
Chassis Mount
-
Package / Case:
TO-240AA
-
detail:
SCR Module 2.2kV Bridge, 3-Phase - SCRs/Diodes - IGBT with Diode Chassis Mount TO-240AA
