MCC310-14IO1 Datasheet
Datasheet specifications
|
Datasheet's name
|
MCC310-14IO1
|
|
File size
|
195.059
KB
|
|
File type
|
pdf
|
|
Number of pages
|
6
|
Technical specifications
-
Manufacturer:
IXYS
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Active
-
Structure:
Series Connection - All SCRs
-
Number of SCRs, Diodes:
2 SCRs
-
Voltage - Off State:
1.4kV
-
Current - On State (It (AV)) (Max):
320A
-
Current - On State (It (RMS)) (Max):
500A
-
Voltage - Gate Trigger (Vgt) (Max):
2V
-
Current - Gate Trigger (Igt) (Max):
150mA
-
Current - Non Rep. Surge 50, 60Hz (Itsm):
9200A, 9800A
-
Current - Hold (Ih) (Max):
150mA
-
Operating Temperature:
-40°C ~ 140°C (TJ)
-
Mounting Type:
Chassis Mount
-
Package / Case:
Module
-
Base Part Number:
MC*310
-
detail:
SCR Module 1.4kV 500A Series Connection - All SCRs Chassis Mount Module
