دیتاشیت MCD312-12IO1
مشخصات دیتاشیت
| نام دیتاشیت |
MCD312-12io1
|
| حجم فایل |
256.429
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
Manufacturer:
IXYS
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Active
-
Structure:
Series Connection - SCR/Diode
-
Number of SCRs, Diodes:
1 SCR, 1 Diode
-
Voltage - Off State:
1.2kV
-
Current - On State (It (AV)) (Max):
320A
-
Current - On State (It (RMS)) (Max):
520A
-
Voltage - Gate Trigger (Vgt) (Max):
2V
-
Current - Gate Trigger (Igt) (Max):
150mA
-
Current - Non Rep. Surge 50, 60Hz (Itsm):
9200A, 10100A
-
Current - Hold (Ih) (Max):
150mA
-
Operating Temperature:
-40°C ~ 140°C (TJ)
-
Mounting Type:
Chassis Mount
-
Package / Case:
Y1-CU
-
Base Part Number:
MC*312
-
detail:
SCR Module 1.2kV 520A Series Connection - SCR/Diode Chassis Mount Y1-CU
