IXGH48N60C3C1 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
IXGH48N60C3C1
|
|
حجم فایل
|
241.337
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
7
|
مشخصات فنی
-
Manufacturer:
IXYS
-
Series:
GenX3™
-
Packaging:
Tube
-
Part Status:
Active
-
IGBT Type:
PT
-
Voltage - Collector Emitter Breakdown (Max):
600V
-
Current - Collector (Ic) (Max):
75A
-
Current - Collector Pulsed (Icm):
250A
-
Vce(on) (Max) @ Vge, Ic:
2.5V @ 15V, 30A
-
Power - Max:
300W
-
Switching Energy:
330µJ (on), 230µJ (off)
-
Input Type:
Standard
-
Gate Charge:
77nC
-
Td (on/off) @ 25°C:
19ns/60ns
-
Test Condition:
400V, 30A, 3Ohm, 15V
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-247-3
-
Supplier Device Package:
TO-247AD (IXGH)
-
Base Part Number:
IXG*48N60
-
detail:
IGBT PT 600V 75A 300W Through Hole TO-247AD (IXGH)
