دیتاشیت MCNA120P2200TA
مشخصات دیتاشیت
| نام دیتاشیت |
MCNA120P2200TA
|
| حجم فایل |
432.777
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات
-
Manufacturer:
IXYS
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Active
-
Structure:
Series Connection - All SCRs
-
Number of SCRs, Diodes:
2 SCRs
-
Voltage - Off State:
2.2kV
-
Current - On State (It (AV)) (Max):
120A
-
Current - On State (It (RMS)) (Max):
190A
-
Voltage - Gate Trigger (Vgt) (Max):
1.5V
-
Current - Gate Trigger (Igt) (Max):
100mA
-
Current - Non Rep. Surge 50, 60Hz (Itsm):
2200A, 2380A
-
Current - Hold (Ih) (Max):
150mA
-
Operating Temperature:
-40°C ~ 140°C (TJ)
-
Mounting Type:
Chassis Mount
-
Package / Case:
TO-240AA
-
detail:
SCR Module 2.2kV 190A Series Connection - All SCRs Chassis Mount TO-240AA
