VHM40-06P1 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: IXYS
- Series: -
- Packaging: Bulk
- Part Status: Not For New Designs
- FET Type: 2 N-Channel (Dual)
- FET Feature: Standard
- Drain to Source Voltage (Vdss): 600V
- Current - Continuous Drain (Id) @ 25°C: 38A
- Rds On (Max) @ Id, Vgs: 70mOhm @ 25A, 10V
- Vgs(th) (Max) @ Id: 5.5V @ 3mA
- Gate Charge (Qg) (Max) @ Vgs: 220nC @ 10V
- Input Capacitance (Ciss) (Max) @ Vds: -
- Power - Max: -
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: ECO-PAC2
- Supplier Device Package: ECO-PAC2
- detail: Mosfet Array 2 N-Channel (Dual) 600V 38A Chassis Mount ECO-PAC2
