MCD312-18IO1 Datasheet
Datasheet specifications
| Datasheet's name | MCD312-18io1 |
|---|---|
| File size | 256.582 KB |
| File type | |
| Number of pages | 6 |
Download Datasheet MCD312-18io1 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: IXYS
- Series: -
- Packaging: Bulk
- Part Status: Active
- Structure: Series Connection - SCR/Diode
- Number of SCRs, Diodes: 1 SCR, 1 Diode
- Voltage - Off State: 1.8kV
- Current - On State (It (AV)) (Max): 320A
- Current - On State (It (RMS)) (Max): 520A
- Voltage - Gate Trigger (Vgt) (Max): 2V
- Current - Gate Trigger (Igt) (Max): 150mA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 9200A, 10100A
- Current - Hold (Ih) (Max): 150mA
- Operating Temperature: -40°C ~ 140°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: Y1-CU
- Base Part Number: MC*312
- detail: SCR Module 1.8kV 520A Series Connection - SCR/Diode Chassis Mount Y1-CU
