CS8-08IO2 Datasheet
Datasheet specifications
| Datasheet's name | CS8 |
|---|---|
| File size | 52.425 KB |
| File type | |
| Number of pages | 3 |
Download Datasheet CS8 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: IXYS
- Series: -
- Packaging: Bulk
- Part Status: Obsolete
- Voltage - Off State: 800V
- Voltage - Gate Trigger (Vgt) (Max): 2.5V
- Current - Gate Trigger (Igt) (Max): 30mA
- Voltage - On State (Vtm) (Max): 1.6V
- Current - On State (It (AV)) (Max): 16A
- Current - On State (It (RMS)) (Max): 25A
- Current - Hold (Ih) (Max): 80mA
- Current - Off State (Max): 3mA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 250A, 270A
- SCR Type: Standard Recovery
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Chassis, Stud Mount
- Package / Case: TO-208AB, TO-64-3, Stud
- Supplier Device Package: TO-64
- detail: SCR 800V 25A Standard Recovery Chassis, Stud Mount TO-64
