CS23-08IO2 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: IXYS
- Series: -
- Packaging: Bulk
- Part Status: Obsolete
- Voltage - Off State: 800V
- Voltage - Gate Trigger (Vgt) (Max): 2.5V
- Current - Gate Trigger (Igt) (Max): 50mA
- Voltage - On State (Vtm) (Max): 1.8V
- Current - On State (It (AV)) (Max): 32A
- Current - On State (It (RMS)) (Max): 50A
- Current - Hold (Ih) (Max): 100mA
- Current - Off State (Max): 3mA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 450A, 480A
- SCR Type: Standard Recovery
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Chassis, Stud Mount
- Package / Case: TO-208AA, TO-48-3, Stud
- Supplier Device Package: TO-208AA (TO-48)
- detail: SCR 800V 50A Standard Recovery Chassis, Stud Mount TO-208AA (TO-48)
