- DSEC60-02AQ
DSEC60-02AQ Datasheet
Datasheet specifications
| Datasheet's name | DSEC60-02AQ |
|---|---|
| File size | 87.324 KB |
| File type | |
| Number of pages | 2 |
Download Datasheet DSEC60-02AQ |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: IXYS
- Series: FRED
- Packaging: Tube
- Part Status: Obsolete
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 200V
- Current - Average Rectified (Io) (per Diode): 30A
- Voltage - Forward (Vf) (Max) @ If: 1.2V @ 30A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 25ns
- Current - Reverse Leakage @ Vr: 3µA @ 200V
- Operating Temperature - Junction: -55°C ~ 175°C
- Mounting Type: Through Hole
- Package / Case: TO-3P-3, SC-65-3
- Supplier Device Package: TO-3P
- detail: Diode Array 1 Pair Common Cathode Standard 200V 30A Through Hole TO-3P-3, SC-65-3
