دیتاشیت DSA9-12F

DS9, DSA9

مشخصات دیتاشیت

نام دیتاشیت DS9, DSA9
حجم فایل 108.407 کیلوبایت
نوع فایل pdf
تعداد صفحات 2

دانلود دیتاشیت DS9, DSA9

DS9, DSA9 Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Avalanche Diodes
  • Datasheet: Littelfuse/IXYS DSA9-12F
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 1.3kV
  • Forward Voltage (Vf@If): 1.4V@36A
  • Reverse Recovery Time (trr): -
  • Reverse Leakage Current (Ir): 3mA@1.2kV
  • Average Rectified Current (Io): 11A
  • Package: DO-203AA
  • Manufacturer: IXYS
  • Series: -
  • Packaging: Bulk
  • Part Status: Obsolete
  • Diode Type: Avalanche
  • Voltage - DC Reverse (Vr) (Max): 1200V
  • Current - Average Rectified (Io): 11A
  • Voltage - Forward (Vf) (Max) @ If: 1.4V @ 36A
  • Speed: Standard Recovery >500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 3mA @ 1200V
  • Capacitance @ Vr, F: -
  • Mounting Type: Chassis, Stud Mount
  • Package / Case: DO-203AA, DO-4, Stud
  • Supplier Device Package: DO-203AA
  • Operating Temperature - Junction: -40°C ~ 180°C
  • detail: Diode Avalanche 1200V 11A Chassis, Stud Mount DO-203AA
