دیتاشیت IXGH60N60C2
مشخصات دیتاشیت
| نام دیتاشیت | IXG(H,T)60N60C2 |
|---|---|
| حجم فایل | 655.468 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت IXG(H,T)60N60C2 |
IXG(H,T)60N60C2 Datasheet |
|---|
مشخصات
- Manufacturer: IXYS
- Series: HiPerFAST™
- Packaging: Tube
- Part Status: Obsolete
- IGBT Type: PT
- Voltage - Collector Emitter Breakdown (Max): 600V
- Current - Collector (Ic) (Max): 75A
- Current - Collector Pulsed (Icm): 300A
- Vce(on) (Max) @ Vge, Ic: 2.5V @ 15V, 50A
- Power - Max: 480W
- Switching Energy: 480µJ (off)
- Input Type: Standard
- Gate Charge: 146nC
- Td (on/off) @ 25°C: 18ns/95ns
- Test Condition: 400V, 50A, 2Ohm, 15V
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247AD (IXGH)
- Base Part Number: IXG*60N60
- detail: IGBT PT 600V 75A 480W Through Hole TO-247AD (IXGH)
