دیتاشیت VMO550-01F

VMO550-01F

مشخصات دیتاشیت

نام دیتاشیت VMO550-01F
حجم فایل 47.8 کیلوبایت
نوع فایل pdf
تعداد صفحات 2

دانلود دیتاشیت VMO550-01F

VMO550-01F Datasheet

مشخصات

  • Manufacturer: IXYS
  • Series: HiPerFET™
  • Packaging: Bulk
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 100V
  • Current - Continuous Drain (Id) @ 25°C: 590A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 2.1mOhm @ 500mA, 10V
  • Vgs(th) (Max) @ Id: 6V @ 110mA
  • Gate Charge (Qg) (Max) @ Vgs: 2000nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 50000pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 2200W (Tc)
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Mounting Type: Chassis Mount
  • Supplier Device Package: Y3-DCB
  • Package / Case: Y3-DCB
  • Base Part Number: VMO
  • detail: N-Channel 100V 590A (Tc) 2200W (Tc) Chassis Mount Y3-DCB
