MCO600-20IO1 数据手册
其他文档
MCO600-20IO1 5 pages
技术规格
- Manufacturer: IXYS
- Series: -
- Packaging: Bulk
- Part Status: Active
- Structure: Single
- Number of SCRs, Diodes: 1 SCR
- Voltage - Off State: 2kV
- Current - On State (It (AV)) (Max): 600A
- Current - On State (It (RMS)) (Max): 928A
- Voltage - Gate Trigger (Vgt) (Max): 2V
- Current - Gate Trigger (Igt) (Max): 300mA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 15000A, 16000A
- Current - Hold (Ih) (Max): 300mA
- Operating Temperature: -40°C ~ 140°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: Y1-CU
- Base Part Number: MCO
- detail: SCR Module 2kV 928A Single Chassis Mount Y1-CU
