MCO450-20IO1 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MCO450-20IO1
|
|
حجم فایل
|
325.049
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
Manufacturer:
IXYS
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Active
-
Structure:
Single
-
Number of SCRs, Diodes:
1 SCR
-
Voltage - Off State:
2kV
-
Current - On State (It (AV)) (Max):
464A
-
Current - On State (It (RMS)) (Max):
750A
-
Voltage - Gate Trigger (Vgt) (Max):
2V
-
Current - Gate Trigger (Igt) (Max):
300mA
-
Current - Non Rep. Surge 50, 60Hz (Itsm):
15000A, 16000A
-
Current - Hold (Ih) (Max):
300mA
-
Operating Temperature:
-40°C ~ 130°C (TJ)
-
Mounting Type:
Chassis Mount
-
Package / Case:
Y1-CU
-
Base Part Number:
MCO
-
detail:
SCR Module 2kV 750A Single Chassis Mount Y1-CU
