دیتاشیت MUBW50-06A8

MUBW50-06A8

مشخصات دیتاشیت

نام دیتاشیت MUBW50-06A8
حجم فایل 640.845 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت MUBW50-06A8

MUBW50-06A8 Datasheet

مشخصات

  • Manufacturer: IXYS
  • Series: -
  • Packaging: Box
  • Part Status: Obsolete
  • IGBT Type: NPT
  • Configuration: Three Phase Inverter with Brake
  • Voltage - Collector Emitter Breakdown (Max): 600V
  • Current - Collector (Ic) (Max): 75A
  • Power - Max: 250W
  • Vce(on) (Max) @ Vge, Ic: 2.3V @ 15V, 50A
  • Current - Collector Cutoff (Max): 800µA
  • Input Capacitance (Cies) @ Vce: 2.8nF @ 25V
  • Input: Three Phase Bridge Rectifier
  • NTC Thermistor: Yes
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Mounting Type: Chassis Mount
  • Package / Case: E3
  • Supplier Device Package: E3
  • Base Part Number: MUBW
  • detail: IGBT Module NPT Three Phase Inverter with Brake 600V 75A 250W Chassis Mount E3
