MWI75-12A8 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: IXYS
- Series: -
- Packaging: Box
- Part Status: Obsolete
- IGBT Type: NPT
- Configuration: Three Phase Inverter
- Voltage - Collector Emitter Breakdown (Max): 1200V
- Current - Collector (Ic) (Max): 125A
- Power - Max: 500W
- Vce(on) (Max) @ Vge, Ic: 2.6V @ 15V, 75A
- Current - Collector Cutoff (Max): 5mA
- Input Capacitance (Cies) @ Vce: 5.5nF @ 25V
- Input: Standard
- NTC Thermistor: No
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: E3
- Supplier Device Package: E3
- Base Part Number: MWI
- detail: IGBT Module NPT Three Phase Inverter 1200V 125A 500W Chassis Mount E3
