TX02-4400PI Datasheet
Datasheet specifications
| Datasheet's name | TX02-4400 |
|---|---|
| File size | 62.367 KB |
| File type | |
| Number of pages | 2 |
Download Datasheet TX02-4400 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: IXYS
- Series: TX02-4400
- Packaging: Tube
- Part Status: Obsolete
- Transformer Type: Isolation and Data Interface (Encapsulated)
- Inductance: -
- ET (Volt-Time): -
- Turns Ratio - Primary:Secondary: 3:1
- Mounting Type: Through Hole
- Size / Dimension: 0.378" L x 0.255" W (9.59mm x 6.48mm)
- Height - Seated (Max): 0.180" (4.57mm)
- Operating Temperature: -55°C ~ 125°C
- Weight: 0.07 oz (1.99 g)
- detail: Isolation and Data Interface (Encapsulated) Pulse Transformer 3:1 Through Hole
