دیتاشیت MITB15WB1200TMH
مشخصات دیتاشیت
| نام دیتاشیت | MITB15WB1200TMH |
|---|---|
| حجم فایل | 187.146 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 8 |
دانلود دیتاشیت MITB15WB1200TMH |
MITB15WB1200TMH Datasheet |
|---|
مشخصات
- Manufacturer: IXYS
- Series: -
- Packaging: Box
- Part Status: Obsolete
- IGBT Type: Trench
- Configuration: Three Phase Inverter with Brake
- Voltage - Collector Emitter Breakdown (Max): 1200V
- Current - Collector (Ic) (Max): 29A
- Power - Max: 100W
- Vce(on) (Max) @ Vge, Ic: 2.2V @ 15V, 15A
- Current - Collector Cutoff (Max): 600µA
- Input Capacitance (Cies) @ Vce: 1.1nF @ 25V
- Input: Three Phase Bridge Rectifier
- NTC Thermistor: Yes
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: MiniPack2
- Supplier Device Package: MiniPack2
- detail: IGBT Module Trench Three Phase Inverter with Brake 1200V 29A 100W Chassis Mount MiniPack2
