DSEE8-08CC 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: IXYS
- Series: HiPerDynFRED™
- Packaging: Tube
- Part Status: Obsolete
- Diode Configuration: 1 Pair Series Connection
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 800V
- Current - Average Rectified (Io) (per Diode): 10A
- Voltage - Forward (Vf) (Max) @ If: 1.53V @ 10A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 30ns
- Current - Reverse Leakage @ Vr: 60µA @ 800V
- Operating Temperature - Junction: -40°C ~ 175°C
- Mounting Type: Through Hole
- Package / Case: ISOPLUS220™
- Supplier Device Package: ISOPLUS220™
- detail: Diode Array 1 Pair Series Connection Standard 800V 10A Through Hole ISOPLUS220™
