OD-454 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: Orient Display
- Series: -
- Part Status: Active
- Number of Characters: 4.5
- Display Format: 4.5 x 1
- Character Format: 7-Segment
- Display Type: TN - Twisted Nematic
- Display Mode: Reflective
- Character Size: 10.20mm H x 5.10mm W
- Outline L x W x H: 50.80mm x 30.50mm x 2.80mm
- Viewing Area: 45.70mm L x 17.70mm W
- Backlight: -
- Voltage - Supply: 3.3V
- Dot Size: -
- Interface: -
- Controller Type: -
- Operating Temperature: -30°C ~ 80°C
- Text Color: Black
- Background Color: Gray
- detail: Character LCD Display Module Reflective 7-Segment TN - Twisted Nematic 50.80mm x 30.50mm x 2.80mm
