AMC0801A دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
AMC0801A
|
|
حجم فایل
|
393.978
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
22
|
مشخصات فنی
-
Manufacturer:
Orient Display
-
Series:
-
-
Part Status:
Active
-
Number of Characters:
8
-
Display Format:
8 x 1
-
Character Format:
5 x 8 Dots
-
Display Type:
STN - Super-Twisted Nematic
-
Display Mode:
Transflective
-
Character Size:
10.75mm H x 6.45mm W
-
Outline L x W x H:
80.00mm x 36.00mm x 13.00mm
-
Viewing Area:
61.00mm L x 15.80mm W
-
Backlight:
LED - Yellow/Green
-
Voltage - Supply:
4.5V ~ 5.5V
-
Dot Size:
1.25mm W x 1.30mm H
-
Interface:
Parallel, 8-Bit
-
Controller Type:
S6A0069
-
Operating Temperature:
-20°C ~ 70°C
-
Text Color:
Dark Blue
-
Background Color:
Yellow/Green
-
detail:
Character LCD Display Module Transflective 5 x 8 Dots STN - Super-Twisted Nematic LED - Yellow/Green Parallel, 8-Bit 80.00mm x 36.00mm x 13.00mm
