دیتاشیت AMC1601AR-B-B6WTDW
مشخصات دیتاشیت
نام دیتاشیت | AMC1601AR-B-B6WTDW |
---|---|
حجم فایل | 444.942 کیلوبایت |
نوع فایل | |
تعداد صفحات | 22 |
دانلود دیتاشیت AMC1601AR-B-B6WTDW |
AMC1601AR-B-B6WTDW Datasheet |
---|
مشخصات
- Manufacturer: Orient Display
- Series: -
- Part Status: Active
- Number of Characters: 16
- Display Format: 16 x 1
- Character Format: 5 x 8 Dots
- Display Type: STN - Super-Twisted Nematic
- Display Mode: Transmissive
- Character Size: 6.56mm H x 3.07mm W
- Outline L x W x H: 80.00mm x 36.00mm x 14.00mm
- Viewing Area: 64.50mm L x 13.80mm W
- Backlight: LED - White
- Voltage - Supply: 4.5V ~ 5.5V
- Dot Size: 0.55mm W x 0.75mm H
- Interface: Parallel, 8-Bit
- Controller Type: S6A0069
- Operating Temperature: -20°C ~ 70°C
- Text Color: White
- Background Color: Blue
- detail: Character LCD Display Module Transmissive 5 x 8 Dots STN - Super-Twisted Nematic LED - White Parallel, 8-Bit 80.00mm x 36.00mm x 14.00mm
