دیتاشیت AMC1602DR-B-Y6WFDY
مشخصات دیتاشیت
نام دیتاشیت | AMC1602DR-B-Y6WFDY |
---|---|
حجم فایل | 337.199 کیلوبایت |
نوع فایل | |
تعداد صفحات | 20 |
دانلود دیتاشیت AMC1602DR-B-Y6WFDY |
AMC1602DR-B-Y6WFDY Datasheet |
---|
مشخصات
- Manufacturer: Orient Display
- Series: -
- Part Status: Active
- Number of Characters: 32
- Display Format: 16 x 2
- Character Format: 5 x 8 Dots
- Display Type: STN - Super-Twisted Nematic
- Display Mode: Transflective
- Character Size: 3.15mm H x 1.85mm W
- Outline L x W x H: 53.00mm x 20.00mm x 8.00mm
- Viewing Area: 36.00mm L x 10.00mm W
- Backlight: LED - Yellow/Green
- Voltage - Supply: 4.5V ~ 5.5V
- Dot Size: 0.33mm W x 0.35mm H
- Interface: Parallel, 8-Bit
- Controller Type: S6A0069
- Operating Temperature: -20°C ~ 70°C
- Text Color: Dark Blue
- Background Color: Yellow/Green
- detail: Character LCD Display Module Transflective 5 x 8 Dots STN - Super-Twisted Nematic LED - Yellow/Green Parallel, 8-Bit 53.00mm x 20.00mm x 8.00mm
