OD-103T 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: Orient Display
- Series: -
- Part Status: Active
- Number of Characters: 1
- Display Format: 1 x 1
- Character Format: 7-Segment
- Display Type: TN - Twisted Nematic
- Display Mode: Transflective
- Character Size: 101.60mm H x 58.70mm W
- Outline L x W x H: 122.56mm x 81.28mm x 2.80mm
- Viewing Area: 76.20mm L x 109.22mm W
- Backlight: -
- Voltage - Supply: 5V
- Dot Size: -
- Interface: -
- Controller Type: -
- Operating Temperature: -20°C ~ 70°C
- Text Color: Black
- Background Color: Gray
- detail: Character LCD Display Module Transflective 7-Segment TN - Twisted Nematic 122.56mm x 81.28mm x 2.80mm
