دیتاشیت AMC1602IR-B-Y6WFDY

AMC1602IR-B-Y6WFDY

مشخصات دیتاشیت

نام دیتاشیت AMC1602IR-B-Y6WFDY
حجم فایل 409.96 کیلوبایت
نوع فایل pdf
تعداد صفحات 22

دانلود دیتاشیت AMC1602IR-B-Y6WFDY

AMC1602IR-B-Y6WFDY Datasheet

مشخصات

  • Manufacturer: Orient Display
  • Series: -
  • Part Status: Active
  • Number of Characters: 32
  • Display Format: 16 x 2
  • Character Format: 5 x 8 Dots
  • Display Type: STN - Super-Twisted Nematic
  • Display Mode: Transflective
  • Character Size: 5.55mm H x 2.95mm W
  • Outline L x W x H: 85.00mm x 30.00mm x 14.00mm
  • Viewing Area: 64.50mm L x 15.50mm W
  • Backlight: LED - Yellow/Green
  • Voltage - Supply: 4.5V ~ 5.5V
  • Dot Size: 0.55mm W x 0.65mm H
  • Interface: Parallel, 8-Bit
  • Controller Type: S6A0069
  • Operating Temperature: -20°C ~ 70°C
  • Text Color: Dark Blue
  • Background Color: Yellow/Green
  • detail: Character LCD Display Module Transflective 5 x 8 Dots STN - Super-Twisted Nematic LED - Yellow/Green Parallel, 8-Bit 85.00mm x 30.00mm x 14.00mm
