AMC2004AR-B-B6WTDW-SPI Datasheet
Datasheet specifications
| Datasheet's name | AMC2004AR-B-B6WTDW-SPI |
|---|---|
| File size | 444.716 KB |
| File type | |
| Number of pages | 18 |
Download Datasheet AMC2004AR-B-B6WTDW-SPI |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Orient Display
- Series: -
- Part Status: Active
- Number of Characters: 80
- Display Format: 20 x 4
- Character Format: 5 x 8 Dots
- Display Type: STN - Super-Twisted Nematic
- Display Mode: Transmissive
- Character Size: 4.75mm H x 2.95mm W
- Outline L x W x H: 98.00mm x 60.00mm x 13.50mm
- Viewing Area: 76.00mm L x 25.20mm W
- Backlight: LED - White
- Voltage - Supply: 4.5V ~ 5.5V
- Dot Size: 0.55mm W x 0.55mm H
- Interface: SPI
- Controller Type: AC780S
- Operating Temperature: -20°C ~ 70°C
- Text Color: White
- Background Color: Blue
- detail: Character LCD Display Module Transmissive 5 x 8 Dots STN - Super-Twisted Nematic LED - White SPI 98.00mm x 60.00mm x 13.50mm
