دیتاشیت AMC2002DR-B-Y6WFDY

مشخصات دیتاشیت

دانلود دیتاشیت AMC2002DR-B-Y6WFDY	AMC2002DR-B-Y6WFDY Datasheet

Manufacturer: Orient Display
Series: -
Part Status: Active
Number of Characters: 40
Display Format: 20 x 2
Character Format: 5 x 8 Dots
Display Type: STN - Super-Twisted Nematic
Display Mode: Transflective
Character Size: 9.52mm H x 5.92mm W
Outline L x W x H: 180.00mm x 40.00mm x 14.00mm
Viewing Area: 149.00mm L x 23.00mm W
Backlight: LED - Yellow/Green
Voltage - Supply: 4.5V ~ 5.5V
Dot Size: 1.12mm W x 1.12mm H
Interface: Parallel, 8-Bit
Controller Type: S6A0069
Operating Temperature: -20°C ~ 70°C
Text Color: Dark Blue
Background Color: Yellow/Green
detail: Character LCD Display Module Transflective 5 x 8 Dots STN - Super-Twisted Nematic LED - Yellow/Green Parallel, 8-Bit 180.00mm x 40.00mm x 14.00mm
