دیتاشیت AMC1601AR-B-Y6NFDY

مشخصات دیتاشیت

دانلود دیتاشیت AMC1601AR-B-B6WTDW	AMC1601AR-B-B6WTDW Datasheet

Manufacturer: Orient Display
Series: -
Part Status: Active
Number of Characters: 16
Display Format: 16 x 1
Character Format: 5 x 8 Dots
Display Type: STN - Super-Twisted Nematic
Display Mode: Transflective
Character Size: 6.56mm H x 3.07mm W
Outline L x W x H: 80.00mm x 36.00mm x 14.00mm
Viewing Area: 64.50mm L x 13.80mm W
Backlight: LED - Yellow/Green
Voltage - Supply: 4.5V ~ 5.5V
Dot Size: 0.55mm W x 0.75mm H
Interface: Parallel, 8-Bit
Controller Type: S6A0069
Operating Temperature: -20°C ~ 70°C
Text Color: Dark Blue
Background Color: Yellow/Green
detail: Character LCD Display Module Transflective 5 x 8 Dots STN - Super-Twisted Nematic LED - Yellow/Green Parallel, 8-Bit 80.00mm x 36.00mm x 14.00mm
