دیتاشیت AMC2002CR-B-G6WFDW

مشخصات دیتاشیت

دانلود دیتاشیت AMC2002CR-B-(B,G)6WTDW	AMC2002CR-B-(B,G)6WTDW Datasheet

Manufacturer: Orient Display
Series: -
Part Status: Active
Number of Characters: 40
Display Format: 20 x 2
Character Format: 5 x 8 Dots
Display Type: STN - Super-Twisted Nematic
Display Mode: Transflective
Character Size: 5.55mm H x 3.20mm W
Outline L x W x H: 116.00mm x 37.00mm x 14.50mm
Viewing Area: 83.00mm L x 18.60mm W
Backlight: LED - White
Voltage - Supply: 4.5V ~ 5.5V
Dot Size: 0.60mm W x 0.65mm H
Interface: Parallel, 8-Bit
Controller Type: S6A0069
Operating Temperature: -20°C ~ 70°C
Text Color: Blue
Background Color: Gray
detail: Character LCD Display Module Transflective 5 x 8 Dots STN - Super-Twisted Nematic LED - White Parallel, 8-Bit 116.00mm x 37.00mm x 14.50mm
