دیتاشیت AMC4004CR-B-Y6WFDY

مشخصات دیتاشیت

دانلود دیتاشیت AMC4004CR-B-Y6WFDY	AMC4004CR-B-Y6WFDY Datasheet

Manufacturer: Orient Display
Series: -
Part Status: Active
Number of Characters: 160
Display Format: 40 x 4
Character Format: 5 x 8 Dots
Display Type: STN - Super-Twisted Nematic
Display Mode: Transflective
Character Size: 4.89mm H x 2.78mm W
Outline L x W x H: 190.00mm x 54.00mm x 14.00mm
Viewing Area: 148.00mm L x 30.30mm W
Backlight: LED - Yellow/Green
Voltage - Supply: 4.5V ~ 5.5V
Dot Size: 0.50mm W x 0.55mm H
Interface: Parallel, 8-Bit
Controller Type: S6A0069
Operating Temperature: -20°C ~ 70°C
Text Color: Dark Blue
Background Color: Yellow/Green
detail: Character LCD Display Module Transflective 5 x 8 Dots STN - Super-Twisted Nematic LED - Yellow/Green Parallel, 8-Bit 190.00mm x 54.00mm x 14.00mm
