دیتاشیت NRF24AP2-USBQ32-R

nRF24AP2-USB Specification

مشخصات دیتاشیت

نام دیتاشیت nRF24AP2-USB Specification
حجم فایل 640.291 کیلوبایت
نوع فایل pdf
تعداد صفحات 44

دانلود دیتاشیت nRF24AP2-USB Specification

nRF24AP2-USB Specification Datasheet

مشخصات

  • RoHS: true
  • Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
  • Data Rate: 1Mbps
  • Datasheet: Nordic Semicon NRF24AP2-USBQ32-R
  • Interface: USB
  • Applications: General-purpose ISM>1GHz
  • Frequency Range: 2.4GHz
  • Receive Current: 22mA
  • Operating Voltage: 4V~5.25V
  • Operating Temperature: -40°C~+85°C
  • Current Of Transmitting: 16mA
  • Package: QFN-32-EP(5x5)
  • Manufacturer: Nordic Semicon
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Type: TxRx Only
  • RF Family/Standard: General ISM > 1GHZ
  • Protocol: ANT™
  • Modulation: GFSK
  • Frequency: 2.4GHz
  • Data Rate (Max): 1Mbps
  • Power - Output: 0dBm
  • Sensitivity: -85dBm
  • Memory Size: -
  • Serial Interfaces: USB
  • Voltage - Supply: 4V ~ 5.25V
  • Current - Receiving: 22mA
  • Current - Transmitting: 16mA ~ 20mA
  • Mounting Type: Surface Mount
  • Package / Case: 32-VFQFN Exposed Pad
  • Supplier Device Package: 32-QFN (5x5)
  • detail: IC RF TxRx Only General ISM > 1GHZ ANT™ 2.4GHz 32-VFQFN Exposed Pad
