دیتاشیت NRF24AP1-REEL7
مشخصات دیتاشیت
| نام دیتاشیت | NRF24AP1 Specification |
|---|---|
| حجم فایل | 387.943 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 25 |
دانلود دیتاشیت NRF24AP1 Specification |
NRF24AP1 Specification Datasheet |
|---|
مشخصات
- Manufacturer: Nordic Semiconductor ASA
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Obsolete
- Type: TxRx Only
- RF Family/Standard: General ISM > 1GHZ
- Protocol: ANT™
- Modulation: GFSK
- Frequency: 2.4GHz
- Data Rate (Max): 1Mbps
- Power - Output: 0dBm
- Sensitivity: -80dBm
- Memory Size: -
- Serial Interfaces: USART
- Voltage - Supply: 1.9V ~ 3.6V
- Current - Receiving: 22mA
- Current - Transmitting: 13mA ~ 16mA
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Package / Case: 24-VQFN Exposed Pad
- Supplier Device Package: 24-QFN (5x5)
- detail: IC RF TxRx Only General ISM > 1GHZ ANT™ 2.4GHz 24-VQFN Exposed Pad
