دیتاشیت NRF51822-CFAC-R7
مشخصات دیتاشیت
| نام دیتاشیت |
nRF51822 Brief
|
| حجم فایل |
214.361
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
2
|
مشخصات
-
RoHS:
true
-
Category:
Radio Frequency Chip/Antenna/RF Transceiver ICs
-
Data Rate:
2Mbps
-
Datasheet:
Nordic Semicon NRF51822-CFAC-R7
-
Interface:
I2C,SPI,UART
-
Applications:
Bluetooth,General-purpose ISM>1GHz
-
Frequency Range:
2.4GHz
-
Receive Current:
8.7mA
-
Operating Voltage:
1.8V~3.6V
-
Operating Temperature:
-25°C~+75°C
-
Current Of Transmitting:
4.7mA
-
Package:
WLCSP-62
-
Manufacturer:
Nordic Semicon
-
Series:
-
-
Part Status:
Active
-
Type:
TxRx + MCU
-
RF Family/Standard:
Bluetooth, General ISM > 1GHz
-
Protocol:
Bluetooth v4.1
-
Modulation:
GFSK
-
Frequency:
2.4GHz
-
Data Rate (Max):
2Mbps
-
Power - Output:
4dBm
-
Sensitivity:
-96dBm
-
Memory Size:
256kB Flash, 32kB RAM
-
Serial Interfaces:
I²C, SPI, UART
-
GPIO:
32
-
Voltage - Supply:
1.8V ~ 3.6V
-
Current - Receiving:
8.7mA ~ 13.4mA
-
Current - Transmitting:
4.7mA ~ 16mA
-
Mounting Type:
Surface Mount
-
Package / Case:
62-UFBGA, WLCSP
-
Supplier Device Package:
62-WLCSP (3.5x3.83)
-
detail:
IC RF TxRx + MCU Bluetooth, General ISM > 1GHz Bluetooth v4.1 2.4GHz 62-UFBGA, WLCSP
