دیتاشیت NRF2401AG-REEL
مشخصات دیتاشیت
| نام دیتاشیت | NRF2401A Specification |
|---|---|
| حجم فایل | 255.02 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 38 |
دانلود دیتاشیت NRF2401A Specification |
NRF2401A Specification Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
- Data Rate: 1Mbps
- Datasheet: Nordic Semicon NRF2401AG-REEL
- Interface: SPI
- Applications: General-purpose ISM>1GHz
- Frequency Range: 2.4GHz
- Receive Current: 18mA
- Operating Voltage: 1.9V~3.6V
- Operating Temperature: -40°C~+85°C
- Current Of Transmitting: 8.8mA
- Package: QFN-24-EP(5x5)
- Manufacturer: Nordic Semicon
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Type: TxRx Only
- RF Family/Standard: General ISM > 1GHZ
- Protocol: -
- Modulation: GFSK
- Frequency: 2.4GHz
- Data Rate (Max): 1Mbps
- Power - Output: 0dBm
- Sensitivity: -93dBm
- Memory Size: -
- Serial Interfaces: SPI
- Voltage - Supply: 1.9V ~ 3.6V
- Current - Receiving: 18mA ~ 25mA
- Current - Transmitting: 8.8mA ~ 13mA
- Mounting Type: Surface Mount
- Package / Case: 24-VQFN Exposed Pad
- Supplier Device Package: 24-QFN (5x5)
- detail: IC RF TxRx Only General ISM > 1GHZ 2.4GHz 24-VQFN Exposed Pad
