- دیتاشیت SN74LVC2G06DCKR
SN74LVC2G06DCKR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74LVC2G06DCKR |
|---|---|
| حجم فایل | 97.949 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 28 |
دانلود دیتاشیت SN74LVC2G06DCKR |
دانلود دیتاشیت |
|---|
سایر مستندات
SN74LVC2G06 32 pages
SN74LVC2G06DCKR 12 pages
مشخصات فنی
- RoHS: true
- Series: 74LVC
- Category: Logic ICs/Inverters
- Datasheet: Texas Instruments SN74LVC2G06DCKR
- Input Type: -
- Sink Current: 32mA
- Source Current: -
- Number of channels: 2
- Supply Current (Max): 10uA
- Low level range (VIL): 0.7V~0.8V
- Max Propagation Delay: 2.9ns@5V,50pF
- Operating Temperature: 40°C~+125°C
- High level range (VIH): 1.7V~2V
- Supply Voltage(Single): 1.65V~5.5V
- Package: SOT-363-6
- Manufacturer: Texas Instruments
- Number of Circuits: 2
- Logic Type: Inverter
- Number of Inputs: 2
- Current - Output High, Low: -, 32mA
- Logic Level - Low: 0.7V ~ 0.8V
- Supplier Device Package: SC-70-6
- Part Status: Active
- Package / Case: 6-TSSOP, SC-88, SOT-363
- Logic Level - High: 1.7V ~ 2V
- Features: Open Drain
- Voltage - Supply: 1.65V ~ 5.5V
- Current - Quiescent (Max): 10µA
- Base Part Number: SN74LVC2G
- Packaging: Cut Tape (CT)
- Max Propagation Delay @ V, Max CL: 2.9ns @ 5V, 50pF
- Mounting Type: Surface Mount
- detail: Inverter IC 2 Channel Open Drain SC-70-6
