دیتاشیت 1P1G3157QDCKRQ1

مشخصات دیتاشیت

دانلود دیتاشیت SN74LVC1G3157-Q1	SN74LVC1G3157-Q1 Datasheet

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments 1P1G3157QDCKRQ1
Turn-on time: 5.7ns
Turn-off time: 3.8ns
Supply Voltage: 1.65V~5.5V
Switch Circuit: SPDT(SPDT)
Number of Channels: 1
On-State Resistance (Max): 15Ω
Package: SC-70-6
Manufacturer: Texas Instruments
Package / Case: 6-TSSOP, SC-88, SOT-363
Series: Automotive, AEC-Q100
Switch Time (Ton, Toff) (Max): 5.7ns, 3.8ns
Supplier Device Package: SC-70-6
Channel Capacitance (CS(off), CD(off)): 5.2pF
Number of Circuits: 1
Channel-to-Channel Matching (ΔRon): 100mOhm
-3db Bandwidth: 300MHz
Charge Injection: 7pC
Multiplexer/Demultiplexer Circuit: 2:1
Packaging: Cut Tape (CT)
Voltage - Supply, Single (V+): 1.65V ~ 5.5V
Voltage - Supply, Dual (V±): -
Base Part Number: 1P1G31
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Current - Leakage (IS(off)) (Max): 1µA
Crosstalk: -54dB @ 10MHz
Part Status: Active
detail: 1 Circuit IC Switch 2:1 15Ohm SC-70-6
