LM317LIDR Datasheet
Datasheet specifications
| Datasheet's name | LM317LIDR |
|---|---|
| File size | 63.054 KB |
| File type | |
| Number of pages | 31 |
Download Datasheet LM317LIDR |
Download Datasheet |
|---|
Other documentations
LM317L Datasheet 33 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LM317LIDR
- Output Type: Adjustable
- Output Current: 100mA
- Output Voltage: 1.2V~32V
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 38V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 2.5mA
- Package: SOIC-8
- Manufacturer: Texas Instruments
- Voltage - Output (Min/Fixed): 1.2V
- PSRR: 80dB ~ 65dB (120Hz)
- Packaging: Cut Tape (CT)
- Base Part Number: LM317
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Current - Output: 100mA
- Control Features: -
- Voltage Dropout (Max): -
- Number of Regulators: 1
- Supplier Device Package: 8-SOIC
- Mounting Type: Surface Mount
- Protection Features: Over Current, Over Temperature, Short Circuit
- Voltage - Output (Max): 32V
- Series: -
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Max): 38V
- detail: Linear Voltage Regulator IC 1 Output 100mA 8-SOIC
