LM317LIPWR Datasheet

LM317LIPWR

Datasheet specifications

Datasheet's name LM317LIPWR
File size 63.054 KB
File type pdf
Number of pages 33

Download Datasheet LM317LIPWR

Download Datasheet

Other documentations

LM317L Datasheet 33 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments LM317LIPWR
  • Output Type: Adjustable
  • Output Current: 100mA
  • Output Voltage: 1.2V~32V
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 38V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 2.5mA
  • Package: TSSOP-8
  • Manufacturer: Texas Instruments
  • Voltage - Output (Min/Fixed): 1.2V
  • PSRR: 80dB ~ 65dB (120Hz)
  • Packaging: Cut Tape (CT)
  • Base Part Number: LM317
  • Package / Case: 8-TSSOP (0.173", 4.40mm Width)
  • Current - Output: 100mA
  • Control Features: -
  • Voltage Dropout (Max): -
  • Number of Regulators: 1
  • Supplier Device Package: 8-TSSOP
  • Mounting Type: Surface Mount
  • Protection Features: Over Current, Over Temperature, Short Circuit
  • Voltage - Output (Max): 32V
  • Series: -
  • Part Status: Active
  • Output Configuration: Positive
  • Voltage - Input (Max): 38V
  • detail: Linear Voltage Regulator IC 1 Output 100mA 8-TSSOP
