LM675 Datasheet

LM675

Datasheet specifications

Datasheet's name LM675
File size 2415.179 KB
File type pdf
Number of pages 16

Download Datasheet LM675

Download Datasheet

Other documentations

LM675T 17 pages

Technical specifications

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Texas Instruments LM675T/NOPB
  • -3db Bandwidth: -
  • Output Current: 3A
  • Number of Circuits: 1
  • Operating Temperature: 0°C~+70°C
  • Current - Input Bias(Ib): 200nA
  • Gain Bandwidth Product(GBP): 5.5MHz
  • Package: TO-220-5
  • Manufacturer: Texas Instruments
  • Voltage - Input Offset: 1mV
  • Current - Supply: 18mA
  • Mounting Type: Through Hole
  • Package / Case: TO-220-5 Formed Leads
  • Amplifier Type: Power
  • Series: -
  • Base Part Number: LM675
  • Part Status: Active
  • Gain Bandwidth Product: 5.5MHz
  • Current - Input Bias: 200nA
  • Voltage - Supply, Single/Dual (±): 10V ~ 60V, ±5V ~ 30V
  • Packaging: Tube
  • Output Type: -
  • Supplier Device Package: TO-220-5
  • Slew Rate: 8V/µs
  • Current - Output / Channel: 3A
  • detail: Power Amplifier 1 Circuit TO-220-5
