دیتاشیت VIPER53EDIP-E
مشخصات دیتاشیت
| نام دیتاشیت | VIPER53EDIP-E, VIPER53ESP-E |
|---|---|
| حجم فایل | 253.396 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 31 |
دانلود دیتاشیت VIPER53EDIP-E, VIPER53ESP-E |
VIPER53EDIP-E, VIPER53ESP-E Datasheet |
|---|
مشخصات
- Manufacturer: STMicroelectronics
- Series: VIPER™
- Packaging: Tube
- Part Status: Active
- Output Isolation: Isolated
- Internal Switch(s): Yes
- Voltage - Breakdown: 620V
- Topology: Flyback
- Voltage - Start Up: 11.5V
- Voltage - Supply (Vcc/Vdd): 8.4V ~ 19V
- Duty Cycle: -
- Frequency - Switching: Up to 300kHz
- Power (Watts): 50W
- Fault Protection: Current Limiting, Over Load, Over Temperature, Short Circuit
- Control Features: EN, Frequency Control, Soft Start
- Operating Temperature: -40°C ~ 150°C (TC)
- Package / Case: 8-DIP (0.300", 7.62mm)
- Supplier Device Package: 8-DIP
- Mounting Type: Through Hole
- Base Part Number: VIPER53
- detail: Converter Offline Flyback Topology Up to 300kHz 8-DIP
