دیتاشیت TS5A3160DBVR

مشخصات دیتاشیت

دانلود دیتاشیت TS5A3160 Datasheet	TS5A3160 Datasheet Datasheet

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments TS5A3160DBVR
Turn-on time: 6ns
Turn-off time: 13ns
Supply Voltage: 1.65V~5.5V
Switch Circuit: SPDT(SPDT)
Number of Channels: 1
Operating Temperature: -40°C~+85°C
On-State Resistance (Max): 0.9Ω
Package: SOT-23-6
Manufacturer: Texas Instruments
Package / Case: SOT-23-6
Series: -
Switch Time (Ton, Toff) (Max): 6ns, 13ns
Supplier Device Package: SOT-23-6
Channel Capacitance (CS(off), CD(off)): 18pF
Number of Circuits: 1
Channel-to-Channel Matching (ΔRon): 50mOhm
-3db Bandwidth: 100MHz
Charge Injection: 36.5pC
Multiplexer/Demultiplexer Circuit: 2:1
Packaging: Cut Tape (CT)
Voltage - Supply, Single (V+): 1.65V ~ 5.5V
Voltage - Supply, Dual (V±): -
Base Part Number: TS5A316
Mounting Type: Surface Mount
Current - Leakage (IS(off)) (Max): 20nA
Crosstalk: -64dB @ 10MHz
Part Status: Active
detail: 1 Circuit IC Switch 2:1 900mOhm SOT-23-6
