دیتاشیت TL720M05QKVURQ1
مشخصات دیتاشیت
| نام دیتاشیت |
TL720M05-Q1
|
| حجم فایل |
1516.038
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
27
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TL720M05QKVURQ1
-
Output Type:
Fixed
-
Output Current:
400mA
-
Output Voltage:
5V~5V
-
Dropout Voltage:
500mV@(300mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
42V
-
Operating Temperature:
-40°C~+125°C@(Ta)
-
Quiescent Current (Ground Current):
220uA
-
Power Supply Rejection Ratio (PSRR):
60dB@(100Hz)
-
Package:
TO-252-3
-
Manufacturer:
Texas Instruments
-
Current - Quiescent (Iq):
220µA
-
Voltage - Input (Max):
42V
-
Packaging:
Digi-Reel®
-
PSRR:
60dB (100Hz)
-
Package / Case:
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Voltage Dropout (Max):
0.5V @ 300mA
-
Current - Output:
400mA
-
Current - Supply (Max):
22mA
-
Number of Regulators:
1
-
Supplier Device Package:
TO-252-3
-
Voltage - Output (Max):
-
-
Mounting Type:
Surface Mount
-
Protection Features:
Short Circuit, Reverse Polarity
-
Base Part Number:
TL720
-
Voltage - Output (Min/Fixed):
5V
-
Control Features:
-
-
Part Status:
Active
-
Series:
Automotive, AEC-Q100
-
Output Configuration:
Positive
-
detail:
Linear Voltage Regulator IC 1 Output 400mA TO-252-3
