TS5A3166DCKR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TS5A3166DCKR |
|---|---|
| حجم فایل | 70.716 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 36 |
دانلود دیتاشیت TS5A3166DCKR |
دانلود دیتاشیت |
|---|
سایر مستندات
TS5A3166 35 pages
TS5A3166DCKR 21 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Texas Instruments TS5A3166DCKR
- Turn-on time: 7ns
- Turn-off time: 11.5ns
- Supply Voltage: 1.65V~5.5V
- Switch Circuit: SPST(SPST)-Normal Open
- Number of Channels: 1
- Operating Temperature: -40°C~+85°C
- On-State Resistance (Max): 0.9Ω
- Package: SC-70-5
- Manufacturer: Texas Instruments
- Channel Capacitance (CS(off), CD(off)): 19pF, 18pF
- Channel-to-Channel Matching (ΔRon): -
- Packaging: Cut Tape (CT)
- Multiplexer/Demultiplexer Circuit: 1:1
- -3db Bandwidth: 200MHz
- Charge Injection: 1pC
- Current - Leakage (IS(off)) (Max): 20nA
- Package / Case: 5-TSSOP, SC-70-5, SOT-353
- Voltage - Supply, Single (V+): 1.65V ~ 5.5V
- Switch Time (Ton, Toff) (Max): 7ns, 11.5ns
- Supplier Device Package: SC-70-5
- Mounting Type: Surface Mount
- Base Part Number: TS5A316
- Voltage - Supply, Dual (V±): -
- Number of Circuits: 1
- Crosstalk: -
- Part Status: Active
- Series: -
- detail: 1 Circuit IC Switch 1:1 900mOhm SC-70-5
