دیتاشیت TMUX1511PWR
مشخصات دیتاشیت
| نام دیتاشیت |
TMUX1511
|
| حجم فایل |
1983.63
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
36
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Texas Instruments TMUX1511PWR
-
Turn-on time:
60us
-
Turn-off time:
4us
-
Switch Circuit:
SPST(SPST)
-
Number of Channels:
4
-
On-State Resistance (Max):
4.5Ω
-
Package:
TSSOP-14
-
Manufacturer:
Texas Instruments
-
Switch Time (Ton, Toff) (Max):
60µs, 4µs
-
Channel-to-Channel Matching (ΔRon):
70mOhm
-
Crosstalk:
-90dB @ 100kHz
-
Part Status:
Active
-
Base Part Number:
TMUX15
-
Voltage - Supply, Dual (V±):
-
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Number of Circuits:
4
-
Packaging:
Cut Tape (CT)
-
Current - Leakage (IS(off)) (Max):
100nA
-
Package / Case:
14-TSSOP (0.173", 4.40mm Width)
-
-3db Bandwidth:
3GHz
-
Series:
-
-
Channel Capacitance (CS(off), CD(off)):
2.5pF, 2.5pF
-
Supplier Device Package:
14-TSSOP
-
Mounting Type:
Surface Mount
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Charge Injection:
2pC
-
detail:
4 Circuit IC Switch 1:1 4.5Ohm 14-TSSOP
