HDMIULC6-4SC6Y 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: STMicroelectronics
- Series: HDMI
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Steering (Rail to Rail)
- Unidirectional Channels: 4
- Voltage - Reverse Standoff (Typ): 5V
- Voltage - Breakdown (Min): 6V
- Voltage - Clamping (Max) @ Ipp: 17V
- Current - Peak Pulse (10/1000µs): 5A (8/20µs)
- Power - Peak Pulse: -
- Power Line Protection: Yes
- Applications: Ethernet, HDMI
- Capacitance @ Frequency: 1pF @ 1MHz
- Operating Temperature: -
- Mounting Type: Surface Mount
- Package / Case: SOT-23-6
- Supplier Device Package: SOT-23-6
- Base Part Number: HDMIULC6
- detail: 17V Clamp 5A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23-6
