دیتاشیت TPS22960DCNR

TPS22960

مشخصات دیتاشیت

نام دیتاشیت TPS22960
حجم فایل 1342.409 کیلوبایت
نوع فایل pdf
تعداد صفحات 29

دانلود دیتاشیت TPS22960

TPS22960 Datasheet

مشخصات

  • Manufacturer: Texas Instruments
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Switch Type: General Purpose
  • Number of Outputs: 2
  • Ratio - Input:Output: 1:1
  • Output Configuration: High Side
  • Output Type: P-Channel
  • Interface: On/Off
  • Voltage - Load: 1.62V ~ 5.5V
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Current - Output (Max): 500mA
  • Rds On (Typ): 342mOhm
  • Input Type: Non-Inverting
  • Features: Load Discharge, Slew Rate Controlled
  • Fault Protection: -
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Supplier Device Package: SOT-23-8
  • Package / Case: SOT-23-8
  • Base Part Number: TPS229
  • detail: Power Switch/Driver 1:1 P-Channel 500mA SOT-23-8
