SN74AUP2G04DCKR دیتاشیت

SN74AUP2G04DCKR

مشخصات دیتاشیت

نام دیتاشیت SN74AUP2G04DCKR
حجم فایل 92.172 کیلوبایت
نوع فایل pdf
تعداد صفحات 25

دانلود دیتاشیت SN74AUP2G04DCKR

دانلود دیتاشیت

سایر مستندات

SN74AUP2G04 25 pages

مشخصات فنی

  • RoHS: true
  • Series: 74AUP
  • Category: Logic ICs/Inverters
  • Datasheet: Texas Instruments SN74AUP2G04DCKR
  • Sink Current: 4mA
  • Source Current: 4mA
  • Number of Inputs: 2
  • Number of Circuits: 2
  • Supply Current (Max): 500nA
  • Low level range (VIL): 0.7V~0.9V
  • Max Propagation Delay: 6.2ns@3.3V,30pF
  • Operating Temperature: -40°C~+85°C
  • High level range (VIH): 1.6V~2V
  • Supply Voltage(Single): 0.8V~3.6V
  • Package: SC-70-6
  • Manufacturer: Texas Instruments
  • Packaging: Cut Tape (CT)
  • Max Propagation Delay @ V, Max CL: 6.2ns @ 3.3V, 30pF
  • Package / Case: 6-TSSOP, SC-88, SOT-363
  • Voltage - Supply: 0.8V ~ 3.6V
  • Base Part Number: SN74AUP
  • Logic Level - Low: 0.7V ~ 0.9V
  • Mounting Type: Surface Mount
  • Supplier Device Package: SC-70-6
  • Current - Quiescent (Max): 500nA
  • Logic Level - High: 1.6V ~ 2V
  • Logic Type: Inverter
  • Features: -
  • Current - Output High, Low: 4mA, 4mA
  • Part Status: Active
  • detail: Inverter IC 2 Channel SC-70-6
